LF Antennas (Antenna Coils)Adoption Example: Realizing Touchless Entrance and Exit Management with an LF Antenna (Antenna Coil)

  • *The entrance and exit management system we look at in this example is only supported in Japan.

Summary

Adopter: Okayama Murata Manufacturing Co., Ltd.

Equipment adopted RX Antenna Coils
Applications BCP (disaster) supported entrance and exit management
Business description Manufacturing of ceramic raw materials, RF modules, LC filters, and inductors

The customer's problems

Background to the Issues

Diversifying work styles, the use of employee welfare facilities before and after working hours, and other factors have made it difficult to accurately track the number of people present in the plant at Okayama Murata Manufacturing. Movement between buildings has also increased. That made it difficult to accurately track who is in which building. Issues have appeared in confirming safety in the event of a disaster because it is not possible to track the number of people present and their location in real time.

Current Situation and Issues in Confirming Safety in the Event of a Disaster

Currently, safety is confirmed using the "tonarigumi system" in which small groups mutually confirm the safety of each individual. However, it takes time to confirm safety with this system because it involves many manual tasks such as checking the people present against a register of names. Moreover, although it is possible to track the number of people who have evacuated using the tonarigumi system, it is not possible to track the number of people who should be present. That means it is not possible to track whether everyone has evacuated safely.
Furthermore, the total system fire extinguishing equipment installed in processes where large amounts of hazardous materials are used is set to activate only after it is confirmed that the employees in the process have evacuated. However, there was no system in place to accurately determine whether everyone had evacuated.
In addition, maintaining tonarigumi management charts is also a burden.

Product adopted by the customer

RX Antenna Coils

  • High reliability conforms to automotive applications.
  • Encapsulated core and winding for anti-shock structure.
  • High sensitivity due to optimized magnetic material and electrode structure.
  • Triaxial LF antenna coil. (SA-X20)
  • Applicable to reflow soldering.
  • RoHS compliant.
Image of RX Antenna Coils

Reasons for Adoption

Murata Manufacturing's RX antenna coils have been adopted in the card-type tags of Matrix Inc.'s entrance and exit management system (safety confirmation function supported) because doing so enables hands-free (touchless) authentication and accurate authentication of multiple people simultaneously.

  • *This disaster safety and location confirmation system for factories of Matrix Inc. has been certified under the Radio Act in Japan only. Please note that it has not been certified outside of Japan.

Benefits

This system has made it possible to automatically track the number of people present in real time because it is possible to confirm authentication information using RFID (contactless IC tags) on an application. The system also enables quick and accurate safety confirmation. Therefore, employees can now proceed smoothly with the initial response in the event of a disaster.
Moreover, it has become possible to quickly make the decision to activate the total system fire extinguishing equipment installed in processes where large amounts of hazardous materials are used.

Mechanism of the Disaster Safety and Location Confirmation System for Factories

The LF-band RFID tags recognize the IDs from the trigger magnetic field and then transmit them as a set with the tag IDs to accurately authenticate multiple people simultaneously.

Mechanism of the Disaster Safety and Location Confirmation System for Factories

Customer's assessment

We feel it is the responsibility of companies to quickly confirm the safety of their employees who are at work in the event of an emergency. This system has made it possible to accurately track the number of employees in the plant in real time and to accurately confirm the evacuation status of those employees in the event of an emergency. This now allows employees to smoothly execute the subsequent initial response and business continuity plan.
It is now possible to quickly make the decision to use the total system fire extinguishing equipment in processes where hazardous materials are used. This allows damage to company assets to be minimized.
Furthermore, it has also reduced the burden of maintaining the tonarigumi chart. That is a great help.
