mmWave Radar Sensor ModulesAutomotive modules

「概念产品」规格如有变更，恕不另行通知。

mmWave Radar sensor modules are ideal for precisely detecting distance, angle of arrival and velocity between target objects in harsh environments.

Image of mmWave Radar Sensor Modules. The antenna design can be customized, so this image is shown as an example only.

Type2VQ
Applications
Features of Type2VQ
Product Information
Evaluation Kit
查询
Supplier

Type2VQ

Murata Type2VQ module is Ultra-small,high quality module which includes TI AWRL6844 chipset and Optimized antenna.
This module is suitable for in-cabin sensing like a CPD^*1, INT^*2, SOD^*3, and OoP^*4.

*1CPD: Child Presence Detection
*2INT: Intruder detection
*3SOD: Seat occupancy detection
*4OoP: Out of position

Applications

Child Presence Detection
Seat Belt Reminder
Airbag Control

eBook download: In-Cabin Radar for Child Protection

Features of Type2VQ

Chipset: Texas Instruments TI AWRL6844 (including C66x DSP for advanced signal processing)
Frequency: 57 to 64GHz Coverage
Built in Patch Antennas
Interface: UART / CAN^*5
Including mmWave radar sensing algorithm^*6

*5CAN transceiver is included in module.
*6If you would like only the mmWave radar sensing algorithm, rather than the module, please contact us separately.

Product Information

Item	Explanation
Product Type	Module
Product Status	Under Development
Grade	Automotive
Chipset	Texas Instruments AWRL6844(Including C66x DSP for advanced signal processing)
Frequency	57 to 64GHz Coverage
CPU Core	ARM Cortex-R5F 200MHz
Flash / RAM	16M-bit Serial Flash Memory
Antenna	Built in Patch Antennas
Operating Temperature Range	−40 to 85 deg.C
Connector to Host	CAN Connector
Package	Plastic housing
Supply Voltage (VBAT)	12.0V typ
Technology	mmWave Radar
Host Interface	UART / CAN^* * CAN transceiver is included in module.
IATF16949	Yes

Evaluation Kit

Item	Explanation
Product P/N	LBVA0ZZ2VQ-EVK
Content	Evaluation kit for Murata Radar module Type2VQ. Interface board includes MCU, switch, BtoB connector, USB connector and so on. Using the interface board enable to evaluate Murata radar module easily with PC.

If you would like to evaluate this solution, please contact us at Inquiries.
