Type 2HL are the advanced long range Sub1GHz Wi-Fi™ HaLow system on module based on NEWRACOM NRC7394 chipset which supports Wi-Fi™ 802.11ah SISO, designed specially to meet the connectivity needs of Internet of Things (IoT). With its exceptional range, low power consumption, Type 2HL are the ideal solution for enabling a wide range of IoT applications. Its capability to connect. Moreover, Wi-Fi™ HaLow incorporates advanced power-saving features, significantly reducing power consumption and greatly extending the battery life of connected devices.
With fully integrated power amplifiers, the Type 2HL offers a robust output of up to 17dBm providing sufficient power for a wide range of IoT applications.
The Type 2HL's standalone mode support enables the execution of a wide range of IoT applications on embedded ARM Cortex-M3. Additionally, the availability of numerous sample applications simplifies the development of new IoT application programs.
